Product description

    Beijing Spacecom Co., LTD.,10 Gigabit Ethernet Media Converter is high-performance 10G optical media converter, Using Optical – Electrical – Electrical wavelength conversion, realize the optical signal equilibrium amplification, clock extraction and optical regeneration, and with WDM (DWDM / CWDM) technology, can achieve optical signals transmit in a single fiber by single or multiple way over a long distance. On the existing network infrastructure, 10 Gigabit Ethernet Media Converter can quickly improve the communication capacity, expand the bandwidth, while using low cost and high cost-effective solutions to manage and operate the system, easy operation and maintenance.

Product features

· 100M/1G/2.5G/5G/10GBase-T to 10GBase-X SFP+ Fiber Media Converter;

· Unit and Port LEDs allow for quick status information;

· Support Auto-negotiation, Auto MDI/MDI-X and Half/Full Duplex mode;

· Support Jumbo Frame;

· Automatic Link Restoration;

· Connect to legacy network equipment;

· Eliminate Collision Domains;

· Support 1U Rack (12 channel) and Standalone use;

· Transparent transport and very low delay;

· Support ITUT prescribed DWDM/CWDM wavelength;

· Support Loopback test function;

· Comply with IEEE 802.3/802.3u/802.3ab/802.3bz/802.3an/802.3ae Ethernet standards;

· Prevent packet loss with back pressure and IEEE 802.3x pause frame flow control;

· SC/FC/ST/LC Connectors optional;

· DIP Switch to set different configurations;

· Compact package size, easy installation;

· Support Link Fault Pass Through (LFP) and Automatic Laser Shutdown (ALS) function;
